In constructing floating or open stair systems, this kit helps install and assemble stair connectors accurately.
Key Features and Uses of the Yellow Stair Connector Jig Kit :
- Jig Functionality:
- The jig holds parts in place and guides the drilling or cutting of precise holes and angles. This is crucial for ensuring that the connectors align correctly and is vital for the stairs’ structural integrity and aesthetic appeal.
- Stair Connectors:
- customers typically use these connectors for joining stair treads to stair stringers or connecting different components of a stair system. The jig kit enables precise placement of the connectors.
- Colour-Coded for Easy Identification:
- The “Yellow” in the name likely refers to the colour of the jig kit and this helps with identification & differentiation from other tools on the job site.
Using the Yellow Stair Connector Jig Kit with a QT13.600 Rail Bolt Kit is as follows
- Measure and Mark:
First, measure and mark the exact location on the handrail and post where you want to install the rail bolt. - Set Up the Jig:
Next, position the Yellow Stair Connector Jig on the marked spot to align it with the intended bolt location. - Drill Holes:
Using the drill bit from the QT13.600 Rail Bolt Kit, drill holes through the handrail and post, guided by the jig for precise placement. - Install the Rail Bolt:
Insert the rail bolt through the drilled hole, ensuring it passes through both the handrail and post. - Secure the Bolt:
Place the washers and nuts onto the bolt and tighten them with a wrench, securing the handrail to the post. - Check and Adjust:
Finally, check the connection to ensure it’s tight and properly aligned, making any necessary adjustments.
By following these steps, you can accurately and securely install a stair handrail using the Yellow Stair Connector Jig Kit and QT13.600 Rail Bolt Kit.
